INMATE PROFILES
Last, but not least, I will use a clustering technique to determine whether there are any common "profiles" of inmates, based on some demographics and the type of crime they were arrested for. Conceptually, this process is very similar to how I text-mined the arrest descriptions to create arrest categories: using measures of similarity to find naturally occurring, relatively homogeneous groups. I am using a method called k-modes, which is similar to the k-means method I used in my last post on the arrest descriptions, but which is more appropriate for the types of variables I'm working with. I don't know how many clusters is the appropriate number, so I'll try 2 through 20 and see if there's a cutoff point beyond which the addition of more clusters does not improve the overall solution by much.
library(MASS) library(rpart) library(klaR) library(caret)
# read in our inmates data, as of approximately 4am CT on 9/3/2016 data <- read.csv("C:/Users/Tammy/Documents/Arrests20160903.csv", header = TRUE, sep="," , stringsAsFactors = TRUE) # finally, we can attempt to cluster the inmates into profiles using k-modes, a method appropriate # for categorical data. In this case, we need all of our data to be categorical, so we'll bucket # Age into factors using the cut() function hist(data$Age)
data$AgeBin <- cut(data$Age, breaks=5) plot(data$AgeBin)
profiles <- kmodes(data[c("AgeBin", "Race", "Sex", "ClusterName")], modes=2) wd <- data.frame(k = 2, wd = sum(profiles$withindiff)) for(k in 3:20){ profiles <- kmodes(data[c("AgeBin", "Race", "Sex", "ClusterName")], modes=k) wd <- rbind(wd, data.frame(k = k, wd = sum(profiles$withindiff))) print(wd[k-1,]) }
## k wd ## 2 3 1180 ## k wd ## 3 4 940 ## k wd ## 4 5 882 ## k wd ## 5 6 897 ## k wd ## 6 7 768 ## k wd ## 7 8 815 ## k wd ## 8 9 714 ## k wd ## 9 10 726 ## k wd ## 10 11 731 ## k wd ## 11 12 681 ## k wd ## 12 13 757 ## k wd ## 13 14 626 ## k wd ## 14 15 739 ## k wd ## 15 16 617 ## k wd ## 16 17 669 ## k wd ## 17 18 622 ## k wd ## 18 19 644 ## k wd ## 19 20 619
plot(wd$k, wd$wd, main = "Within Cluster Sum of Squared Differences")
profiles <- kmodes(data[c("AgeBin", "Race", "Sex", "ClusterName")], modes=5) results <- profiles$modes results
## AgeBin Race Sex ClusterName ## 1 (17.9,29.6] White Male Misc ## 2 (29.6,41.2] White Male Misc ## 3 (29.6,41.2] White Female Probation Violation ## 4 (29.6,41.2] Black Male Misc ## 5 (17.9,29.6] White Female Misc
# # AgeBin Race Sex ClusterName # 1 (29.6,41.2] White Male Misc # 2 (17.9,29.6] Black Male Misc # 3 (29.6,41.2] White Female Probation Violation # 4 (41.2,52.8] White Male Narcotics # 5 (41.2,52.8] Black Male Misc profiles$size
## cluster ## 1 2 3 4 5 ## 394 180 96 116 55
# cluster sizes # cluster # 1 2 3 4 5 # 468 148 112 81 32 # middle aged white men # young black men # middle aged white females on probation violation # older white men on narcotics charges # older black men profiles2 <- kmodes(data[c("AgeBin", "Race", "Sex", "ClusterName")], modes=12) results2 <- profiles2$modes results2
## AgeBin Race Sex ClusterName ## 1 (17.9,29.6] White Male Misc ## 2 (17.9,29.6] White Female Misc ## 3 (41.2,52.8] White Male Misc ## 4 (29.6,41.2] White Female Probation Violation ## 5 (29.6,41.2] Black Male Misc ## 6 (52.8,64.4] Black Male Narcotics ## 7 (41.2,52.8] Black Male Misc ## 8 (17.9,29.6] Black Male Probation Violation ## 9 (29.6,41.2] White Male DWI/Intoxication ## 10 (17.9,29.6] Black Male Narcotics ## 11 (64.4,76.1] White Male Interference ## 12 (17.9,29.6] Black Female Probation Violation
